Part Information
  • TYPE:   Spark Plug
  • PART NO:   YPSP-0355
  • ATTRIBUTES:   Thread: M 14 x 1.25
     (ft.lbs): 21 FT. LBS
    Connect Type: DIN/SAE top, non-removable
    Tightening torque: 28 Nm
    Ground Electrode: 1
    Seal: flat deformable
    Center electrode diameter: 0.8 mm
    Electrode spacing: 1 mm
    Interference/Ablation Suppression: 6 kOhm
    spark position: 4 mm
    ThreadLength: 19 mm
    Wrench opening: 16 mm

  • OEM Number
  • AUD      101 905 631 F
  • AUD      101 905 611 A
  • BERU      14 F-7 KPPRU2
  • BOSCH      0 242 236 583
  • BOSCH      0242236583
  • BOSCH      FR7KPP332U
  • NGK      PFR6X-11
  • OPE      32017036
  • VAG      101 905 631E
  • VAG      101 905 631F
  • VOL      32017036
  • VWW      101 905 611 D
  • VWW      101 906 631 E
  • VWW      101 905 611 A
  • VWW      101 905 631 F
  • APPLICATION
  • AUDI      AUDI A5 (8T3) 3.2 FSI quattro 07/06 - /
  • AUDI      AUDI A5 Convertible (8F7) 3.2 FSI quattro 09/03 - /
  • AUDI      AUDI A5 Convertible (8F7) S5 quattro 09/06 - /
  • AUDI      AUDI A6 (4F2, C6) 2.8 FSI 06/11 - 08/10
  • AUDI      AUDI A4 (8K2, B8) S4 quattro 08/11 - /
  • AUDI      AUDI A6 Avant (4F5, C6) 2.8 FSI quattro 07/06 - 08/10
  • AUDI      AUDI A5 (8T3) 3.2 FSI 07/06 - /
  • AUDI      AUDI A5 Convertible (8F7) 3.2 FSI 09/03 - /
  • AUDI      AUDI A5 Sportback (8TA) S5 quattro 10/01 - /
  • AUDI      AUDI A4 (8K2, B8) 3.2 FSI quattro 07/11 - /
  • AUDI      AUDI Q5 (8R) 3.2 FSI quattro 08/11 - /
  • AUDI      AUDI A6 Avant (4F5, C6) 2.8 FSI 06/11 - 08/10
  • AUDI      AUDI A4 Avant (8K5, B8) S4 quattro 08/11 - /
  • AUDI      AUDI A5 Sportback (8TA) 3.2 FSI quattro 09/09 - /
  • AUDI      AUDI A4 (8K2, B8) 3.2 FSI 08/09 - /
  • AUDI      AUDI A8 (4E_) 2.8 FSI 07/08 - 10/07
  • AUDI      AUDI A6 (4F2, C6) 2.8 FSI quattro 07/06 - 08/10
  • AUDI      AUDI A4 Avant (8K5, B8) 3.2 FSI quattro 08/04 - /
  • AUDI      AUDI A4 Avant (8K5, B8) 3.2 FSI 08/09 - /
  • Similar Products
    YPSP-0350

    Thread: M 14 x 1.25 (ft.lbs): 21 FT. LBS Connect Type: DIN/SAE top, non-removable Tightening torque: 28 Nm Ground Electrode: 1 Seal: flat deformable Center electrode diameter: 0.8 mm Electrode spacing: 0.9 mm Interference/Ablation Suppression: 6 kOhm spark position: 3 mm ThreadLength: 19 mm Wrench opening: 16 mm

    YPSP-0351

    weight: 0.042kg connection terminal: DIN/SAE Nuts can be unscrewed Tightening torque: 28 Ground Electrode quantity: 1 Oil seal seat: Hollow flat washer Center electrode diameter: 0.3 Electrode spacing: 0.8 resistance: 3kOhm spark position: 4 ThreadLength: 19 Hex size (spark plug): 16mm Thread: M 14 x 1,25

    YPSP-0352

    weight: 0.042kg connection terminal: DIN/SAE Nuts can be unscrewed Tightening torque: 28 Ground Electrode quantity: 1 Oil seal seat: Hollow flat washer Center electrode diameter: 0.3 Electrode spacing: 1.1 resistance: 3kOhm spark position: 4 ThreadLength: 19 Hex size (spark plug): 16mm Thread: M 14 x 1,25

    YPSP-0353

    weight: 0.042kg connection terminal: DIN/SAE Nuts can be unscrewed Tightening torque: 28 Ground Electrode quantity: 1 Oil seal seat: Hollow flat washer Center electrode diameter: 0.3 Electrode spacing: 1.1 resistance: 3kOhm spark position: 5 ThreadLength: 19 Hex size (spark plug): 16mm Thread: M 14 x 1,25

    YPSP-0354

    weight: 0.046kg connection terminal: DIN/SAE can't let go of the head Tightening torque: 20 Ground Electrode quantity: 1 Oil seal seat: conical Center electrode diameter: 0.6 Electrode spacing: 0.9 resistance: 6kOhm spark position: 4 ThreadLength: 25 Hex size (spark plug): 16mm Thread: M 14 x 1,25

    YPSP-0356

    Thread: M 14 x 1.25 (ft.lbs): 21 FT. LBS Connect Type: DIN/SAE nut, unscrewable Tightening torque: 28 Nm Ground Electrode: 1 Seal: flat deformable Center electrode diameter: 2.6 mm Electrode spacing: 1 mm Interference/Ablation Suppression: 6 kOhm spark position: 3 mm ThreadLength: 19 mm Wrench opening: 20.8 mm

    YPSP-0357

    Connect Type: DIN/SAE top, non-removable

    YPSP-0358

    Length(No Paking): 76.98 mm Width(No Paking): 19 mm Thread: M 14 x 1.25 (ft.lbs): 21 FT. LBS Connect Type: DIN/SAE top, non-removable Tightening torque: 28 Nm Ground Electrode: 1 Seal: flat deformable Center electrode diameter: 0.6 mm Electrode spacing: 1.3 mm Interference/Ablation Suppression: 6 kOhm spark position: 4 mm ThreadLength: 19 mm Wrench opening: 16 mm

    YPSP-0359

    Thread: M 14 x 1.25 (ft.lbs): 21 FT. LBS Connect Type: DIN/SAE top, non-removable Tightening torque: 28 Nm Ground Electrode: 1 Seal: flat deformable Center electrode diameter: 0.5 mm Electrode spacing: 1 mm Interference/Ablation Suppression: 6 kOhm spark position: 3 mm ThreadLength: 19 mm Wrench opening: 20.8 mm

    YPSP-0360

    Thread: M 14 x 1.25 (ft.lbs): 15 FT. LBS Connect Type: DIN/SAE top, non-removable Tightening torque: 20 Nm Ground Electrode: 1 Seal: conical Center electrode diameter: 0.8 mm Electrode spacing: 0.9 mm Interference/Ablation Suppression: 6 kOhm spark position: 3 mm ThreadLength: 25 mm Wrench opening: 16 mm
